ELECTRICALLY CONDUCTIVE, MODIFIED SILVER EPOXY INK
DESCRIPTION: 102-05F is an electrically conductive ink, coating and adhesive suitable for screen printing very
narrow circuit lines. This product features excellent adhesion to Kapton, Mylar, glass and a variety of other
substrates. Unlike conventional conductive materials, this product is very resistant to abrasion and scratching.
Some applications for 102-05F include, but are not limited to, emi/rfi shielding of polyimide flexible circuits, polymer
thick film circuitry, membrane switches, electrical attachments for surface mounted devices, and for bonding to
Indium Tin Oxide (ITO) sputtered surfaces. 102-05F can be further cross-linked with B187 curing agent for
applications requiring resistance to solvents and high humidity. Refer to handling instructions for additional
information.
TYPICAL CURED PROPERTIES:
Consistency Smooth Paste
Filler Silver
Percent Silver (cured) 85
Crease Resistance Excellent
Volume Resistance (Ω-cm) 0.00005
Sheet Resistivity (Ω/sq./mil) 0.019
Solderable No
Solvent Resistance Excellent
