用于3D打印导电银浆油墨

Printing Process and Materials
The inkjet-printing process was performed with a Dimatix Materials Printer (DMP) 2831 and an installed piezoelectric printhead with 16 nozzles, which have a distance of 254 µm (Figure 2). The piezoelectric elements are driven by a voltage waveform. A silver nano-particle ink PE410 was used and printed on a PET substrate Melinex 506 (Teijin Films) which has a thickness of 100 µm. The solid content of the ink is 45.2 wt% dissolved in Butyldiglycol and octylamine [11]. The PET substrate consists of an adhesion promoting pre-treatment
印刷工艺与材料
喷墨打印过程是用迪马提克斯材料打印机完成的。(DMP)2831和一个安装有16个喷嘴的压电打印头，其距离为254μm（图2）。压电元件由电压波形驱动。采用银纳米粒子油墨PE410，在厚度为100μm的PET基板Melinex 506（Teijin薄膜）上印刷。油墨的固含量为45.2%（重量%），溶解在丁基二甘醇和辛胺中。[11]。PET基材包括促进附着力的预处理

Metallic Nanoparticle Inks for 3D Printing of Electronics

The three‐dimensional (3D) printed electronics additive manufacturing industry sector has grown substantially in the past few years, and there is increasing demand for different types of metallic nanoparticle inks in electronics printing for various applications. Metallic nanoparticle inks are commonly used for fabricating conductive tracks and patterns due to their relatively high electrical conductivity as compared to other types of inks, and they can be further categorized into single‐element metallic nanoparticle inks, alloy metallic nanoparticle inks, metallic oxide nanoparticle inks, and core–shell bimetallic nanoparticle (BNP) inks. It is critical to gain a deep understanding of the metallic nanoparticle inks used in 3D printed electronics as the material properties of these inks can directly affect the final electrical and mechanical properties of the printed patterns. This review presents an overview of the available metallic nanoparticle inks used for 3D printing of electronics, and critically reviews the strengths and weaknesses of each type of ink. Finally, the challenges of metallic nanoparticle inks in 3D printed electronics are also discussed along with the future outlook for 3D printed electronics.

用于电子3D打印的金属纳米颗粒油墨

三维（3D）打印电子增材制造行业在过去几年中已取得实质性增长，并且在电子印刷中针对各种应用对不同类型的金属纳米粒子油墨的需求不断增长。与其他类型的墨水相比，金属纳米粒子墨水具有较高的电导率，因此通常用于制造导电迹线和图案，并且可以进一步分为单元素金属纳米粒子墨水，合金金属纳米粒子墨水，金属氧化物纳米粒子墨水。和核壳双金属纳米粒子（BNP）油墨。深入了解3D打印电子产品中使用的金属纳米颗粒油墨至关重要，因为这些油墨的材料性能会直接影响印刷图案的最终电气和机械性能。这篇评论概述了可用于电子3D打印的金属纳米粒子油墨，并严格地审查了每种油墨的优缺点。最后，还讨论了3D打印电子产品中金属纳米颗粒油墨的挑战以及3D打印电子产品的未来前景。
