EMS (Nagese Group)EMS has been offering a variety of conductive and dielectric inks for printed electronics for more than 20 years. EMS believes that all applications are unique and specific, so EMS’s ability to define, plan and create solutions for customers is superior to competitors.EMS CI-1001
Screen printing inks with silver particles for printing conductive tracks.
Filler – Ag
Viscosity – 17,000 cps
Curing to conductivity – 10 min at 110 ° C
Layer thickness – 7-15 µm
Electrical resistance – 0.015 Ω
Screen printing inks with silver particles when durability is required for flexible and resilient surfaces.
Filler – Ag
Viscosity – 10,000 cps
Curing to conductivity – 10 min at 120 ° C
Layer thickness – 7-15 µm
Electrical resistance – 0.010 Ω
Screen printing dielectric inks for coating conductive inks are mixed with silver inks or for resistor printing. Carbon-based screen printing inks, usually printed on conductive inks such as CI-1001, at contact locations to ensure physical and environmental protection.
Aggregate – carbon
Viscosity – 25,000 cps
Curing to conductivity – 10 min at 120 ° C
Layer thickness – 10-20 µm
Electrical resistance – 50 Ω
EMS 生产了许多产品，但使它们在客户服务方面表现出色的主要概念之一是能够根据客户的需求创建指定的材料。他们拥有实验室设施，可以混合不同的材料来定制配方产品。 EMS 在开发国际范围内的解决方案方面非常具有创造性。凭借研发和对其配方产品的深入了解，EMS 成为粘合剂、密封剂和灌封解决方案的全球领导者。有关 更多信息或了解 Engineered Material Systems 如何定义、开发和创建适合您公司的工程材料解决方案，请访问 www.gzyinbiao.com。或致电13922125860（微信同步）我司提供专业的商务合作和技术对接！
