DuPont BQ331
A screen printable, solvent-based gold conductive ink used for working electrodes in biosensors
MATERIAL NOTES
DuPont™ BQ331 is a solvent-based conductive gold ink that is used for working electrodes in biosensors. The formulation is well suited for excellent sensitivity providing high signal to noise ratios in many types of designs. It can be screen printed using a 200SS mesh screen yielding 0.0005" and can be dried at 130-140°C for 1-5 minutes. The ink can be diluted with 8210 FOR REFERENCE ONLY
KEY PROPERTIES
Adhesion - No material removal
Coverage - 36 cm²/g/mil
Flexibility - N/A
Operating Temp - N/A
Viscosity Pa - 15-30 Pa∙s
Volume Resistivity - 500 mohms/sq/mil
杜邦BQ331
可打印的，基于溶剂的金色导电墨水，用于生物传感器中的工作电极
材料笔记
Dupont™BQ331是一种基于溶剂的导电金墨水，用于生物传感器中的工作电极。 该公式非常适合出色的灵敏度，可在许多类型的设计中提供高信号与噪声比。 它可以使用200SS网格屏幕打印，得出0.0005“，可以在130-140°C下干燥1-5分钟。只能用8210稀释墨水以供参考
关键属性
粘附 - 无物质去除
覆盖范围-36cm²/g/mil
灵活性-N/A
操作温度-N/A
粘度PA -15-30 PA∙S
音量电阻率-500 MOHMS/sq/mil
BIOSENSOR MATERIALS
DESCRIPTION
The Ercon E4464 coating system contains a proprietary fine gold dispersion in a resin system for printing
highly conductive patterns with controlled electrical properties on substrates. These conductive coatings can
be applied using many standard printing techniques, including screen-printing, and possess good wear
characteristics, flexibility, and good adhesion to many substrates when properly dried.
The Ercon E4464 system is a member of Ercon's '400' series. Ercon's '400' series includes silver/silver
chloride, silver, gold, graphite, carbon, and other conductive formulations which can be used in conjunction
with the E4464 system.
APPLICATIONS
The Ercon E4464 coating system has been engineered for disposable diagnostics and biosensor
applications for the rapid determination, analysis, and monitoring of bodily fluid and environmental
constituents. The controlled electrical properties of the E4464 system are also useful for many diverse
commercial applications.
TYPICAL PHYSICAL PROPERTIES
Vehicle Type
Polyester Polymer System
Pigment Type
Gold
Gold
Color
Solids Weight
78.0 + 1.0%
Theoretical Coverage (Dry)
25.5 in²/gm (16.5 m²/kg) @ 0.25 Mil (6.4µ) Dry
Surface Resistivity (Max)
0.25 Ohms/Square/Mil
Flash Point
75°C (167°F) TCC
Shelf Life
6 Months @ 10 - 27°C (50 - 80°F) Unopened
生物传感器材料
描述
ERCON E4464涂料系统在树脂系统中包含专有的细黄色色散
高导电模式，具有底物上的电气性能。这些导电涂层可以
使用许多标准打印技术，包括屏幕打印，并具有良好的磨损
正确干燥后，特性，灵活性和良好的粘附。
ERCON E4464系统是ERCON的“ 400”系列的成员。 ERCON的“ 400”系列包括银/银
氯化物，银，金，石墨，碳和其他可用于联合使用的导电配方
使用E4464系统。
申请
ERCON E4464涂料系统已用于一次性诊断和生物传感器
快速确定，分析和监测身体流体和环境的应用
成分。 E4464系统的受控电气性能也可用于许多多样化
商业应用。
典型的物理特性
媒介物聚酯聚合物系统
颜料型黄金
金色
固体重量78.0 + 1.0％
理论覆盖范围（干）25.5英寸/gm（16.5平方米/千克） @ 0.25 mil（6.4µ）干燥
表面电阻率（最大）0.25欧姆/平方/mil
闪点75°C（167°F）TCC
保质期6个月 @ 10-27°C（50-80°F）
我司供应全球知名品牌的导电金浆，铂浆等材料，以上如有需求请致电13922125860
